大功率空冷自增湿PEMFC温度控制方法

doi:10.3969/j.issn.0258-2724.2015.01.007

基金项目:

国家科技计划支撑资助项目(2014BAG08B01)

国家自然科学基金资助项目(51177138)

铁道部科技研究开发计划资助项目(2012J012-D)

高等学校博士学科点专项科研基金资助项目(20120184120011)

详细信息

作者简介:
游志宇(1980-), 男, 博士研究生, 研究方向为新能源技术及其应用、混合动力系统能量管理及应用, E-mail: youzhiyu@my.swjtu.edu.cn

计量
- 文章访问数:1291
- HTML全文浏览量:130
- PDF下载量:612
- 被引次数:0
出版历程
- 收稿日期:2014-01-15
- 刊出日期:2015-02-25

Temperature Control of High-Power Self-Humidifying PEMFC with Air Cooling

摘要

摘要:为研究大功率空冷自增湿质子交换膜燃料电池(PEMFC)温度控制对电堆输出性能的影响,分别采用模糊控制、PID控制、模糊-PID切换控制、自适应模糊PID控制对电堆进行试验测试.实验结果表明,不同控制方法在负载变化时的动态响应特性存在较大差异:模糊控制对电堆输出性能影响较大,在大电流输出时会造成明显的浓差极化;模糊控制、PID控制、模糊-PID切换控制在负载变化时动态响应存在较大的超调量,调节时间长;模糊自适应PID控制超调量小,调节时间短.与PID温度控制相比,自适应模糊PID温度控制超调量降低了75%,调节时间加快了20%.综合考虑调节时间、超调量、稳态误差、电堆输出性能等因素,自适应模糊PID温度控制有利于提高大功率空冷自增湿PEMFC输出特性.
- 空冷/
- 自增湿/
- 质子交换膜燃料电池/
- 模糊控制/
- PID控制/
- 模糊-PID切换控制/
- 自适应模糊PID控制
Abstract:To study the influence of temperature control on the stack output performance of high-power self-humidifying proton exchange membrane fuel cell (PEMFC) with air cooling, four control methods including fuzzy control, PID control, fuzzy-PID switching control, and adaptive fuzzy PID control are employed to test the stack. Results show that distinct differences exist in response performances of the stack among different control methods with load variations. More specifically, the fuzzy control has a greater influence on the output performance of the stack, resulting in obvious concentration polarization with heavy current output. In addition, when the load changes, problems of excessive overshoot in dynamic response and long regulation time exist in the fuzzy control, PID control, and fuzzy-PID switching control, while the adaptive fuzzyPID control has tiny overshoot and short regulation time. Compared with the PID temperature control, the adaptive fuzzy PID temperature control reduces the overshoot by at least 75%, and reduces the regulation time by at least 20%. By comprehensively evaluating the typical parameters such as regulation time, overshoot, control error, and the stack output performance, the adaptive fuzzyPID temperature control is favorable to improve the output performance of the high-power self-humidifying PEMFC with air cooling.
- air cooling/
- self-humidifying/
- PEMFC/
- fuzzy control/
- PID control/
- fuzzy-PID switching control/
- adaptive fuzzyPID control

HTML全文

参考文献 (35)

PEIGHAMBARDOUST S J, ROWSHANZAMIR S, AMJADI M. Review of the proton exchange membranes for fuel cell applications

[J]. Journal of Hydrogen Energy, 2010, 35(17): 9349-9384.

HAN H S, KIM Y H, KIM S Y, et al. Development of proton exchange membrane fuel cell system for portable refrigerator

[C]//Proc. of the 2011 Fuel Cell Seminar and Exposition. Orlando: ECS Transactions, 2011, 42(1): 149-153.

HOSSEINZADEH E, ROKNI M. Development and validation of a simple analytical model of the proton exchange membrane fuel cell(PEMFC) in a fork-lift truck power system

[J]. Journal of Green Energy, 2013, 10(5): 523-543.

ZHAN Yuedong, ZHU Jianguo, GUO Youguang, et al. Performance analysis and improvement of a proton exchange membrane fuel cell using comprehensive intelligent control

[C]//Proc. of the 11th International Conference on Electrical Machines and Systems. Wuhan: ICEMS, 2008: 2378-2383.

杨涛,史鹏飞. 新型自增湿燃料电池组性能研究

[J]. 电源技术,2008,32(2): 80-83. YANG Tao, SHI Pengfei. Study on performance of novel self-humidified fuel cell

[J]. Chinese Journal of Power Sources, 2008, 32(2): 80-83.

周靖,张晓维,谈金祝,等. 操作参数对PEMFC性能的影响

[J]. 南京工业大学学报:自然科学版,2013,35(4): 78-81. ZHOU Jing,ZHANG Xiaowei,TAN Jinzhu, et al. Effects of operating parameters on performance of PEMFC

[J]. Journal of Nanjing University of Technology: Natural Science Edition, 2013, 35(4): 78-81.

COPPO M, SIEGEL N P, SPAKOVSKY M R. On the influence of temperature on PEM fuel cell operation

[J]. Journal Power Sources, 2006, 159(1): 560-569.

SANTA R D T, PINTO D G, SILA V S, et al. High performance PEMFC stack with open-cathode at ambient pressure and temperature conditions

[J]. Journal of Hydrogen Energy, 2007, 32(17): 4350-4357.

HASIKOS J, SARIMVEIS H, ZERVAS P L, et al. Operational optimization and real-time control of fuel-cell systems

[J]. J. Power Sources, 2009, 193(1): 258-268.

HADDAD A, BOUYEKHF R, MOUDNI A. Dynamic modeling and water management in proton exchange membrane fuel cell

[J]. Journal of Hydrogen Energy, 2008, 32(21): 6239-6252.

卫东,郑东,褚磊民. 空冷型质子交换膜燃料电池堆最优性能输出控制

[J]. 化工学报,2010,61(5): 1293-1300. WEI Dong, ZHENG Dong, CHU Leimin. Output control of optimal performance for air-cooling PEMFC stack

[J]. Journal of Chemical Industry and Engineering, 2010, 61(5): 1293-1300.

王斌锐,金英连,褚磊民,等. 空冷燃料电池最佳温度及模糊增量PID控制

[J]. 中国电机工程学报,2009,29(8): 109-114. WANG Binrui, JIN Yinglian, CHU Leimin, et al.Temperature optimization and fuzzy incremental PID control for air-breathing proton exchange membrane fuel cell stack

[J]. Proceedings of the CSEE, 2009(8): 109-114.

LI Q, CHEN W, LIU S, et al. Temperature optimization and control of optimal performance for a 300 W open cathode proton exchange membrane fuel cell

[J]. Procedia Engineering, 2012, 29(1): 179-183.

李奇,陈维荣,贾俊波,等. 质子交换膜燃料电池动态特性建模及其控制

[J]. 江南娱乐网页版入口官网下载安装学报,2009,44(4): 604-608. LI Qi, CHEN Weirong, JIA Junbo, et al. Dynamic character isticmodeling and control of proton exchange membrane fuel cell

[J]. Journal of Southwest Jiaotong University, 2009, 44(4): 604-608.

XIA Wen, QI Zhidong. Dynamic modeling and fuzzy PID control study on proton exchange membrane fuel cell

[C]//2010 2nd Conference on Environmental Science and Information Application Technology. Wuhan: ESIAT, 2010, 3: 116-119.
