拟静力分量对列车-轨道-桥梁系统地震响应的影响

doi:10.3969/j.issn.0258-2724.2015.01.018

基金项目:

国家自然科学基金资助项目(51378429,51308470)

国家973计划资助项目(2013CB036301)

国家863计划资助项目(2011AA11A103)

详细信息

作者简介:
雷虎军(1986-), 男, 讲师, 博士, 研究方向为大跨度桥梁抗震及车桥耦合振动, 电话:18558787526, E-mail:leihujun@yeah.net

计量
- 文章访问数:1608
- HTML全文浏览量:109
- PDF下载量:22906
- 被引次数:0
出版历程
- 收稿日期:2013-12-15
- 刊出日期:2015-02-25

Effects of Structural Quasi-static Components on Seismic Responses of Train-Track-Bridge System

摘要

摘要:为探讨结构拟静力分量对地震作用下高速铁路桥上列车行车安全性的影响,考虑路基和桥梁地震力边界条件,分别采用相对运动法和大质量法,在相对坐标系和绝对坐标系下处理地震力边界条件,建立了不同坐标系下的列车-轨道-桥梁系统地震响应分析模型.以跨度48 m+580 m+48 m的刚构-连续组合梁桥为例,分析了结构单向和三向拟静力分量对列车-轨道-桥梁系统地震响应的影响.结果表明:结构横向拟静力分量将显著增大桥梁横向位移、钢轨横向位移、列车脱轨系数和轮重减载率,而纵向、竖向拟静力分量的影响甚微;同时考虑结构的三向拟静力分量时,列车脱轨系数和轮重减载率均显著增大,且其相对误差随列车速度提高而增大,最大达30.5%和22.2%.因此,不考虑结构拟静力分量在列车速度较高时将严重低估车辆的动力响应,对桥上列车的行车安全性造成误判.
- 列车-轨道-桥梁系统/
- 地震响应/
- 拟静力分量/
- 大质量法/
- 相对运动法
Abstract:In order to discuss the effects of structural quasi-static components on the running safety of a train running over a high-speed railway bridge subjected to earthquake action, two dynamic models for a train-track-bridge system subjected to seismic excitation were set up by considering the seismic force boundaries of subgrade and bridge in relative coordinates and absolute coordinates, and the seismic force boundaries were processed respectively by the relative movement method and the large mass method. A rigid-continuous combination beam bridge with spans of 48 m+580 m+48 m was taken as an example, and the effects of structural quasi-static components in different directions on the seismic responses of the train-track-bridge system were analyzed. The research results show that the transversal quasi-static component causes a significant increase in dynamic responses, including the transversal displacements of bridge and rail, derailment coefficient and wheel unloading rate. The longitudinal and vertical quasi-static components have little effect on the seismic responses of the coupling system. When the quasi-static components of all three directions are considered, the derailment coefficient and wheel unloading rate of train increase significantly, their relative errors increase with the raising of train speed and the maximum relative errors can reach 30.5% and 22.2%, respectively. So, if the effects of structural quasi-static components are ignored to a train running through a bridge under earthquake action at a high speed, the dynamic responses of vehicle will be substantially undervalued to lead to an incorrect judgment of the running safety.
- train-track-bridge system/
- seismic response/
- quasi-static components/
- large mass method/
- relative movement method

HTML全文

参考文献 (36)

XIA H, HAN Y, ZHANG N, et al. Dynamic analysis of train-bridge system subjected to non-uniform seismic excitations

[J]. Earthquake Engineering Structural Dynamics, 2006, 35(12): 1563-1579.

邓子铭,郭向荣,张志勇. 地震作用对钢桁梁桥车桥系统耦合振动的影响分析

[J]. 中南大学学报:自然科学版,2011,42(1): 184-191. DENG Ziming, GUO Xiangrong, ZHANG Zhiyong. Coupled vibration of train-bridge system of steel truss bridge with seismic effect

[J]. Journal of Central South University: Science and Technology, 2011, 42(1): 184-191.

熊建珍,高芒芒,俞翰斌. 天兴洲长江大桥斜拉桥在地震作用下的车-桥耦合振动分析

[J]. 中国铁道科学,2006,27(5): 54-59. XIONG Jianzhen, GAO Mangmang, YU Hanbin. Vehicle-bridge coupling vibration analysis of cable-stayed bridge of Tianxingzhou Yangtze River bridge under earthquakes

[J]. China Railway Science, 2006, 27(5): 54-59.

韩艳,夏禾,郭薇薇. 斜拉桥在地震与列车荷载同时作用下的动力响应分析

[J]. 工程力学,2006,23(1): 93-98. HAN Yan, XIA He, GUO Weiwei. Dynamic response of cable-stayed bridge to running trains and earth-quakes

[J]. Engineering Mechanics, 2006, 23(1): 93-98.

王少林,翟婉明. 地震作用下高速列车-线路-桥梁系统动力响应

[J]. 江南娱乐网页版入口官网下载安装学报,2011,46(1): 56-62. WANG Shaolin, ZHAI Wanming. Dynamic responses of high-speed train-track-bridge system under seismic exci-tations

[J]. Journal of Southwest Jiaotong University, 2011, 46(1): 56-62.

ZHANG N, XIA H, De ROECK G. Dynamic analysis of a train-bridge system under multi-support seismic excitations

[J]. Journal of Mechanical Science and Technology, 2010, 24(11): 2181-2188.

YANG Y B, WU Y S. Dynamic stability of trains moving over bridges shaken by earthquakes

[J]. Journal of Sound and Vibration, 2002, 258(1): 65-94.

DU X T, XU Y L, XIA H. Dynamic interaction of bridge-train system under non-uniform seismic ground motion

[J]. Earthquake Engineering Structural Dynamics, 2012, 41(1): 139-157.

李小珍. 高速铁路列车-桥梁系统耦合振动理论及应用研究

[D]. 成都:江南娱乐网页版入口官网下载安装土木工程学院,2000.

刘德军. 风-列车-线路-桥梁系统耦合振动研究

[D]. 成都:江南娱乐网页版入口官网下载安装土木工程学院,2010.

雷虎军,李小珍. 非一致地震激励下列车-轨道-桥梁耦合振动模型

[J]. 江南娱乐网页版入口官网下载安装学报,2013,48(5): 803-809. LEI Hujun, LI Xiaozhen. Dynamic model for train-track-bridge coupling system subjected to non-uniform seismic excitation

[J]. Journal of Southwest Jiaotong University, 2013, 48(5): 803-809.

翟婉明,夏禾. 列车-轨道-桥梁动力相互作用理论与工程应用

[M]. 北京:科学出版社,2011: 97-98.

VERMEULEN J K, JOHNSON K L. Contact of non-spherical bodies transmitting tangential forces

[J]. Journal of Applied Mechanics, 1964, 31: 338-340.

李小珍,雷虎军. 基于多点激励的刚构-连续组合梁桥行波效应分析

[J]. 桥梁建设,2012,42(6): 33-38. LI Xiaozhen, LEI Hujun. Analysis of traveling wave effect of hybrid bridge of rigid-frame and continuous girder based on multi-support excitation

[J]. Bridge Construction, 2012, 42(6): 33-38.

翟婉明. 车辆-轨道耦合动力学

[M]. 3版. 北京:科学出版社,2007: 38-78.
