Transient Analysis of ZPW-2000 Track Circuit Based on FDTD Interface Method
-
摘要:轨道电路在列车驶入/出清时存在暂态过程，可以利用接收端信号的暂态突变对轨道电路的状态进行判断. 时域有限差分（finite-difference，time-domain，FDTD）方法是求解传输线的常用数值解法，但ZPW-2000轨道电路结构比一般轨道电路更加复杂，直接采用FDTD法并不适用. 基于此，提出了一种基于FDTD和ATP-EMTP（alternative transients program-electromagnetic transients program）接口模型的ZPW-2000轨道电路暂态分析方法. 该方法将整个模块分为传输线与集中参数网络两个部分，其中，传输线采用FDTD求解，集中参数网络在ATP-EMTP中计算，两个部分用受控电流源关联. 对ZPW-2000轨道电路的仿真结果表明：道床电阻和分路电阻对接收端信号幅值有较大的影响，当道床电阻降至0.6 Ω•km时接收端电压从2.0 V下降到0.5 V左右，当分路电阻增至0.2 Ω时接收端残压达到了1.0 V左右，此时若仅采用门限比对的方法难以区分轨道电路的状态；然而，在列车驶入/出清的瞬间，接收端信号存在暂态突变，可根据突变特性实现轨道电路分路态的检测.Abstract:A track circuit performs a transient process when a train enters or departs a section. Therefore, its circuit state can be judged by the transient change of signals at the receiving end. The finite-difference, time-domain (FDTD) is a common numerical solution for the transmission line. However, the structure of the ZPW-2000 track circuit is more complex than that of general ones. Thus, the direct FDTD method does not work well. Therefore, an FDTD-based transient analysis method and an alternative transient program-electromagnetic transients program (ATP-EMTP) interface model for a ZPW-2000 track circuit is introduced. The entire module is divided into two parts: transmission line and centralised parameter network. The two parts are related by a controlled current source. The transmission line is solved using FDTD, and the centralised parameter network is solved using the ATP-EMTP. The simulation results of the ZPW-2000 track circuit show that the ballast and shunt residences have great impacts on the receiving-end signals. When the ballast resistance falls to 0.6 Ω•km, the receiving-end voltage drops from 2.0 V to about 0.5 V; when the shunt resistance increases to 0.2 Ω, the residual voltage at the receiving end rises to about 1.0 V. If only the threshold comparison method is used, the state of the track circuit is indistinguishable. However, a transient mutation ccurs in the receiving-end signals when the train enters or departs. This can be used to determine the shunt state of the track circuit.
-
Key words:
- track circuit/
- FDTD methods/
- ATP-EMTP/
- interface technique/
- transient analysis
-
图 3端接集中参数元件传输线的FDTD & ATP-EMTP接口方案
Figure 3.FDTD and ATP-EMTP interface scheme for transmission lines with lumped loads at line terminations
图 4并联集中参数元件传输线的FDTD & ATP-EMTP接口方案
Figure 4.FDTD and ATP-EMTP interface scheme for transmission lines including shunt-connected components
图 5基于FDTD & ATP-EMTP接口技术的传输线暂态分析模型
Figure 5.Transient analysis model of transmission lines based on FDTD and ATP-EMTP interface technique
图 7基于FDTD & ATP-EMTP接口技术的ZPW-2000轨道电路暂态分析模型
Figure 7.Transient analysis model of ZPW-2000 track circuit based on FDTD and ATP-EMTP interface technique
图 8列车驶入及出清时接收端信号仿真结果
Figure 8.Simulation results of the receiving-end signal when the train enters or departs
图 9道床电阻对接收端信号幅值包络的影响
Figure 9.Effect of the ballast resistance on the amplitude envelope of receiving-end signals
图 10列车驶入和出清时分路电阻对接收端信号幅值包络的影响
Figure 10.Effect of the shunt resistance on the amplitude envelope of receiving-end signals when train enters or departs
表 1轨道电路参数信息
Table 1.Basic parameters of the track circuit
载频/Hz 长度/m 补偿电容 模拟电缆
长度/km真实电缆
长度/km发送电压
/V匹配变压
器变比道床电阻
/（Ω•km）数量 容值/μF 间距/m 1 700 848 10 40 80 7、6 2.74、3.62 89.7 1∶11 5
下载:
导出CSV
-
米根锁,王彦快,王文波. 雷达图法在轨道电路分路不良预警中的应用[J]. 铁道学报,2013,35(11): 66-70doi:10.3969/j.issn.1001-8360.2013.11.011MI Gensuo, WANG Yankuai, WANG Wenbo. Application of radar chart in poor shunting early warning for track circuit[J]. Journal of the China Railway Society, 2013, 35(11): 66-70doi:10.3969/j.issn.1001-8360.2013.11.011 孙上鹏,赵会兵,全宏宇,等. 基于定性趋势分析的无绝缘轨道电路电气绝缘节设备故障诊断方法[J]. 中国铁道科学,2014,35(1): 105-113doi:10.3969/j.issn.1001-4632.2014.01.17SUN Shangpeng, ZHAO Huibing, QUAN Hongyu, et al. Equipment fault diagnosis for electrical separation joint of jointless track circuit using qualitative trend analysis[J]. China Railway Science, 2014, 35(1): 105-113doi:10.3969/j.issn.1001-4632.2014.01.17 赵斌,张友鹏,魏蕾. 轨道电路时域响应分析[J]. 铁道学报,2014,36(9): 68-72doi:10.3969/j.issn.1001-8360.2014.09.13ZHAO Bin, ZHANG Youpeng, WEI Lei. Analysis on time responses of track circuits[J]. Journal of the China Railway Society, 2014, 36(9): 68-72doi:10.3969/j.issn.1001-8360.2014.09.13 赵斌,张友鹏. 基于傅里叶变换结合Q-D算法的轨道电路暂态分析[J]. 铁道学报,2015,37(11): 78-83ZHAO Bin, ZHANG Youpeng. Transient analysis of track circuits based on FFT & Q-D algorithm[J]. Journal of the China Railway Society, 2015, 37(11): 78-83 傅佳伟,王小敏,郭进. ZPW-2000轨道电路的多轮对动态分路建模研究[J]. 铁道科学与工程学报,2018,15(9): 2374-2384doi:10.3969/j.issn.1672-7029.2017.02.030FU Jiawei, WANG Xiaomin, GUO Jin. Research on dynamic multi-wheel sets shunted track circuit modeling[J]. Journal of Railway Science and Engineering, 2018, 15(9): 2374-2384doi:10.3969/j.issn.1672-7029.2017.02.030 张友鹏,祁欢,赵斌. 轨道电路分路态检测方法研究[J]. 铁道学报,2017,39(1): 70-75doi:10.3969/j.issn.1001-8360.2017.01.010ZHANG Youpeng, QI Huan, ZHAO Bin. Research on method for detection of shunt state of track circuits[J]. Journal of the China Railway Society, 2017, 39(1): 70-75doi:10.3969/j.issn.1001-8360.2017.01.010 赵会兵,章宇舟,汪希时. 电容补偿式轨道电路若干问题的研究[J]. 铁道学报,1998,20(4): 77-81doi:10.3321/j.issn:1001-8360.1998.04.014ZHAO Huibing, ZHANG Yuzhou, WANG Xishi. Study on some problems of track circuit with compensating capacitors[J]. Journal of the China Railway Society, 1998, 20(4): 77-81doi:10.3321/j.issn:1001-8360.1998.04.014 PAUL C R. Analysis of multi-conductor transmission lines[M]. New York: Wiley, 1994: 240-258 刘少斌, 刘崧, 洪伟. 色散介质时域有限差分方法[M]. 北京: 科学出版社, 2010: 49-67 YUICHI T. Circuit-based FDTD method for transient analysis of mutually coupled system[C]//Proceedings of the 15th IEEE International Conference Electronics, Circuits and Systems. Washington D C: IEEE, 2008: 101-104 RACHIDI F, NUCCI C A, IANOZ M. Transient analysis of multi-conductor lines above a lossy ground[J]. IEEE Transactions on Power Delivery, 1999, 14(1): 294-302doi:10.1109/61.736741 PAOLONE M, NUCCI C A, PETRACHE E, et al. Mitigation of lightning-induced over-voltages in medium voltage distribution lines by means of periodical grounding of shielding wires and of surge arresters:Modeling and experimental validation[J]. IEEE Transactions on Power Delivery, 2004, 19(1): 423-431doi:10.1109/TPWRD.2003.820196 Leuven EMTP Center. ATP/EMTP rule book[M]. Leuven: Belgium, 1987: 128-154 -
下载:
点击查看大图
图(10)/
表(1)
