Switching Scheme of Multi-mode Modulation Based on Selected Harmonic Elimination Pulse Width Modulation
-
摘要:为了抑制切换过程电流和转矩冲击，提出了一种基于特定次谐波消除脉宽调制（SHEPWM）的多模式调制平滑切换算法. 根据SHEPWM算法的基本原理分析了相电压波形谐波分布情况；基于异步电机等效电路模型得到不同开关角个数下各次电流谐波幅值和调制度的关系；将切换过程抽象为电流基波及各次谐波的一阶暂态响应过程，建立了切换过程的数学模型，从电路原理的角度分析了切换冲击的产生机理；基于RT-LAB半实物实验平台对两种切换算法进行了硬件在环半实物试验对比. 研究结果表明：谐波幅值突变是造成转矩冲击的原因，在相电压基波相位π/2和3π/2处切换谐波电流幅值不发生变化，相电流可以平滑过渡；三相无法同时满足相位为π/2或3π/2的条件，因此分别在相电压基波相位π/2和3π/2处切换，切换过程电流和转矩冲击得到有效抑制.
-
关键词:
- 脉宽调制/
- 特定次谐波消除脉宽调制（SHEPWM）/
- 牵引控制/
- 低开关频率/
- 切换策略
Abstract:In order to suppress the current and torque shock, a switching scheme of multi-mode modulation based on selected harmonic elimination pulse width modulation (SHEPWM) was proposed. Based on the basic principle of SHEPWM, the spectrum of phase voltage was analyzed. The relationship between current harmonics and modulation index was acquired with different switching angle numbers. Then, the switching process was abstracted as the first-order transient response of the fundamental circuit and harmonics circuits, and the mathematic model of the switching process was built. The mechanism of current shock during switching process was analyzed. Hardware-in-loop (HIL) experiments of two switching schemes were carried out on the RT-LAB HIL experimental platform. The results indicate that the main cause of the torque shock is the harmonic current amplitude step change during the switching process, and the harmonic currents amplitude keeps constant when switching at π/2 or 3π/2, so the phase current switches smoothly. The three phase currents can’t satisfy the phase requirement at the same time, so each phase switching at π/2 or 3π/2 separately can suppress the current and torque shock effectively. -
图 1电流谐波幅值随调制变化曲线
Figure 1.Trajectories of current harmonics with respect to modulation index
图 2切换过程基波等效电路
Figure 2.Equivalent circuit for the fundamental wave during switching process
图 6N= 3切换至N= 2时电流、开关信号波形
Figure 6.Experimental results of currents and switching signals when switching fromN= 3 toN= 2
图 7N= 3切换至N= 2时转矩、开关信号波形
Figure 7.Experimental results of torque and switching signals when switching fromN= 3 toN= 2
图 8全速域转矩、定子频率与切换信号波形
Figure 8.Experimental results of torque，stator frequency and switching signal of modulation mode in whole speed range
表 1试验参数
Table 1.Parameters in the experiments
参数 数值 参数 数值 额定功率/kw 562 定子漏感/mH 1.241 额定电压/V 2 750 转子漏感/mH 1.864 额定频率/Hz 140 互感/mH 3.472 定子电阻/Ω 0.097 4 极对数 2 转子电阻/Ω 0.064 6 转动惯量/（kg•m2） 200
下载:
导出CSV
-
冯晓云. 电力牵引交流传动及其控制系统[M]. 北京: 高等教育出版社, 2009: 121-126. 吴瑕杰,宋文胜,冯晓云. 一种在线计算多模式空间矢量调制算法及其FPGA实现[J]. 电工技术学报,2016,31(18): 124-133.doi:10.3969/j.issn.1000-6753.2016.18.016WU Xiajie, SONG Wensheng, FENG Xiaoyun. An on-line calculation multi-mode SVPWM algorithm and implementation based on FPGA[J]. Transactions of China Electro-Technical Society, 2016, 31(18): 124-133.doi:10.3969/j.issn.1000-6753.2016.18.016 何亚屏,文宇良,许峻峰,等. 基于多模式SVPWM算法的永磁同步牵引电机弱磁控制策略[J]. 电工技术学报,2012,27(3): 92-99.HE Yaping, WEN Yuliang, XU Junfeng, et al. High-power permanent magnet fiux-weakening strategy based on multi-mode SVPWM[J]. Transactions of China Electro-Technical Society, 2012, 27(3): 92-99. 王治国,郑泽东,李永东,等. 轨道交通车辆牵引电传动系统的调制与控制策略[J]. 电工技术学报,2016,31(24): 223-232.WANG Zhiguo, ZHENG Zedong, LI Yongdong, et al. Modulation and control strategy for electric traction drive system of rail transit ehicles[J]. Transactions of China Electro-Technical Society, 2016, 31(24): 223-232. 谭新元. 牵引逆变器SHEPWM控制技术的研究[J]. 中国电机工程学报,2001,21(9): 48-53.TAN Xinyuan. Advanced SHEPWM technique for AC traction drives[J]. Proceedings of the CSEE, 2001, 21(9): 48-53. 李世军,罗隆福,佘双翔,等. 基于空间矢量和特定消谐脉宽调制的三电平逆变器调制方法[J]. 电工技术学报,2015,30(12): 34-40.doi:10.3969/j.issn.1000-6753.2015.12.005LI Shijun, LUO Longfu, SHE Shuangxiang, et al. A method of SVPWM and SHEPWM applied to three-level NPC inverter[J]. Transactions of China Electro-technical Society, 2015, 30(12): 34-40.doi:10.3969/j.issn.1000-6753.2015.12.005 张志刚,黄守道,胡存刚,等. 三电平SHEPWM与SVPWM混合控制策略及其矢量平滑切换方法的研究[J]. 电工技术学报,2015,30(14): 343-349.ZHANG Zhigang, HUANG Shoudao, HU Cungang, et al. Hybrid method of three-level SHEPWM and SVPWM and its vector smooth-switching[J]. Transactions of China Electro-technical Society, 2015, 30(14): 343-349. YANG Haitao, ZHANG Yongchang, YUAN Guofeng, et al. Hybrid synchronized PWM schemes for closed loop current control of high power motor drives[J]. IEEE Transactions on Industrial Electronics, 2017, 64(9): 6920-6929.doi:10.1109/TIE.2017.2686298 DIAO L J, TANG J, CHIANG L P, et al. An efficient DSP-FPGA-based implementation of hybrid PWM for electric rail traction induction motor control[J]. IEEE Transactions on Power Electronics, 2017(99): 1-10. ZHANG Yongchang, ZHAO Zhenming, ZHU Jianguo. A hybrid PWM applied to high-power three-level inverter-fed induction-motor drives[J]. IEEE Transactions on Industrial Electronics, 2011, 58(8): 3409-3420.doi:10.1109/TIE.2010.2090836 张永昌,赵争鸣. 三电平逆变器SHEPWM多组解计算方法[J]. 电工技术学报,2007,22(1): 74-78.doi:10.3321/j.issn:1000-6753.2007.01.013ZHANG Yongchang, ZHAO Zhengming. Multiple solutions for selective harmonic eliminated PWM applied to three-level inverter[J]. Transactions of China Electro-technical Society, 2007, 22(1): 74-78.doi:10.3321/j.issn:1000-6753.2007.01.013 费万民,张艳莉,都小利. 五电平逆变器特定谐波消除脉宽调制方法[J]. 电工技术学报,2009,24(2): 85-93.doi:10.3321/j.issn:1000-6753.2009.02.014FEI Wanming, ZHANG Yanli, DU Xiaoli. Selective harmonic elimination PWM method for five-level inverters[J]. Transactions of China Electro-Technical Society, 2009, 24(2): 85-93.doi:10.3321/j.issn:1000-6753.2009.02.014 郑春芳,张波,丘东元. 基于沃尔什函数的逆变器选择性谐波消除技术开关角的快速求解[J]. 中国电机工程学报,2005,25(22): 41-47.ZHENG Chunfang, ZHANG Bo, QIU Dongyuan. Fast-solving switching angles of inverter's selected harmonic elimination technique with walsh function[J]. Proceedings of the CSEE, 2005, 25(22): 41-47. 郑春芳,张波. 吴方法在电力电子逆变器消谐技术中的应用[J]. 中国电机工程学报,2005,25(15): 40-45.doi:10.3321/j.issn:0258-8013.2005.15.008ZHENG Chunfang, ZHANG Bo. Application of wu method to harmonic elimination techniques[J]. Proceedings of the CSEE, 2005, 25(15): 40-45.doi:10.3321/j.issn:0258-8013.2005.15.008 罗辞勇,王英豪,王卫耀,等. 单相特定谐波消除脉宽调制高频逆变器的死区补偿策略[J]. 电工技术学报,2017,32(14): 155-164.LUO Ciyong, WANG Yinghao, WANG Weiyao, et al. Study of dead-time compensation strategy in selective harmonic elimination PWM inverter[J]. Transactions of China Electro-Technical Society, 2017, 32(14): 155-164. 胡存刚,胡军,陈权,等. 基于特定谐波消除PWM的三电平有源中点钳位逆变器共模电压抑制方法[J]. 电工技术学报,2016,31(16): 93-102.doi:10.3969/j.issn.1000-6753.2016.16.012HU Cungang, HU Jun, CHEN Quan, et al. Suppression method of commod-mode voltage for three-level active neutral-point-clamped inverter based on selective harmonics elimination PWM[J]. Transactions of China Electro-Technical Society, 2016, 31(16): 93-102.doi:10.3969/j.issn.1000-6753.2016.16.012 李威,车向中,郝荣泰. 交-直-交电力机车PWM调制方法研究[J]. 铁道学报,2000,22(6): 26-31.doi:10.3321/j.issn:1001-8360.2000.06.006LI Wei, CHE Xiangzhong, HAO Rongtai. Research on PWM method for AC-DC-AC electric locomotive[J]. Journal of the China Railway Society, 2000, 22(6): 26-31.doi:10.3321/j.issn:1001-8360.2000.06.006 周明磊,李强,游小杰,等. 基于SHEPWM的多模式调制切换策略研究[J]. 铁道学报,2014,36(1): 34-39.ZHOU Minglei, LI Qiang, YOU Xiaojie, et al. Research on SHEPWM-based switching strtegy of multi-mode modulation[J]. Journal of the China Railway Society, 2014, 36(1): 34-39. -
