Multi-objective Matching Optimization for Hybrid Fuel-Cell Power System in Trams
-
摘要:有轨电车燃料电池混合动力系统配置对整车动力性能、系统效率及经济效益具有重要影响，但是目前缺乏有效的优化匹配方法. 基于有轨电车沿线动态工况下的牵引功率计算，提出了面向服役周期成本最低的燃料电池有轨电车混合动力系统匹配优化方法. 以混合动力系统整车服役周期成本最低、体积/重量最小为目标函数，以动力性能、直流母线电压、电源输出功率、功率/能量实时平衡、储能系统充放电倍率及其充放电深度和SOC （state of charge） 为约束条件，建立了多目标多约束配置优化模型. 采用多目标优化方法获取Pareto前沿，同时给出了体积/重量可接受、经济性最优的推荐方案确定方法. 仿真结果表明，多目标匹配优化方法配置的有轨电车燃料电池混合动力系统满足了所有设计指标，混合动力系统全寿命周期成本从7 000万元降为1 500万元.Abstract:The hybrid power system configuration in fuel-cell trams greatly affects the vehicle dynamic performance, system efficiency and economic benefit. However, there is a lack of effective configuration optimization methods. To meet the objective of minimizing the cost in a vehicle service cycle, an optimal configuration method for fuel-cell hybrid power system is proposed on the basis of the traction power calculation in the dynamic conditions of trams. The multi-objective and multi-constraint optimization model of the fuel-cell hybrid power system is established with the minimum volume/weight and the minimum vehicle service cycle cost. Meanwhile, the dynamic demand, bus voltage, power source output, real time electric power balance, rates and depths of charge and discharge, and SOC (state of charge) of energy storage system are all taken into consideration. A Pareto front is obtained by the proposed method, and the optimal solution with the minimum cost and the acceptable volume/weight is also recommended. Finally, the simulation results show that the optimal hybrid fuel-cell power system configured by the proposed method can meet the design requirements, and the service cycle cost of the hybrid power system is reduced from 70 million yuan to 15 million yuan.
-
图 3混合动力系统配置优化流程
Figure 3.Flow chart of configuration optimization of hybrid power system
表 1混合动力机车主要设计参数
Table 1.Specifications of hybrid tram
参数 取值 车重/t 58 载客量/人 360 车轮半径/m 0.333 辅助功率/kW 40 最大速度/（km•h−1） 70 巡航速度/（km•h−1） 30 最大加速度/（m•s−2） 1.2 平均加速度（0～70 km/h）/ （m•s−2） 0.6 最大爬坡度/‰ 50
下载:
导出CSV
表 2燃料电池主要参数
Table 2.Main parameters of fuel cells
参数 取值 总功率/kW 150 电压范围/V 465～750 最大电流/A 320 质量/kg 404 尺寸/mm 1 530/871/495 下载:
导出CSV
表 3动力电池主要参数
Table 3.Main parameters of batteries
参数 取值 额定电压/V 2.4 额定容量/（A•h） 26 体积/m−3 6.40 × 10−4 功率单价/（元•W−1） 1.5 容量单价/（元•W−1•h−1） 1.0 维护单价/（× 10−5元•W−1•h−2） 5.0 循环寿命/次 20 000 下载:
导出CSV
表 4超级电容主要参数
Table 4.Main parameters of supercapacitors
参数 取值 额定电压/V 48 额定容量/F 165 体积//m−3 0.014 5 功率单价/（元•W−1） 1.5 容量单价/（元•W−1•h−1） 27.0 维护单价/（× 10−5元•W−1•h−2） 5.0 循环寿命/次 500 000 下载:
导出CSV
表 5燃料电池混合动力系统推荐方案
Table 5.Optimal configuration of fuel-cell hybrid system
燃料电池 动力电池 超级电容 150 kW 1 套 15 串 6 并 216 串 3 并 下载:
导出CSV
-
陈维荣,钱清泉,李奇. 燃料电池混合动力列车的研究现状与发展趋势[J]. 江南娱乐网页版入口官网下载安装学报,2009,44(1): 1-6.doi:10.3969/j.issn.0258-2724.2009.01.001CHEN Weirong, QIAN Qingquan, LI Qi. Investigation status and development trend of hybrid power train based on fuel cell[J]. Journal of Southwest Jiaotong University, 2009, 44(1): 1-6.doi:10.3969/j.issn.0258-2724.2009.01.001 陈维荣,时方力,戴朝华,等. 基于动态混合度的储能式有轨电车能量管理策略[J]. 江南娱乐网页版入口官网下载安装学报,2020,55(2): 412-419.CHEN Weirong, SHI Fangli, DAI Chaohua, et al. Energy management strategy of hybrid tram based on dynamic degree of hybrd[J]. Journal of Southwest Jiaotong University, 2020, 55(2): 412-419. GARCIA P, FEMANDEZ L M, CARCIA C A, et al. Energy management system of fuel-cell-battery hybrid tramway[J]. IEEE Transaction on Industrial Electronics, 2010, 57(12): 4013-4023.doi:10.1109/TIE.2009.2034173 TERAVA N, FUJII M T. Development of an NE train[J]. J. R. East Technical Review, 2006, 156(4): 62-70. 张海军,马永红. 现代有轨电车无接触网供电方案比较分析[J]. 现代交通技术,2013,10(4): 79-82.ZHANG Haijun, MA Yonghong. Comparative analysis of no-catenary power supply modes for modern trams[J]. Modern Transportation Technology, 2013, 10(4): 79-82. CHEN Weirong, PENG Fei, LIU Zhixiang, et al. System integration of China's first PEMFC loco-motive[J]. Journal of Modern Transportation, 2013, 21(3): 163-168.doi:10.1007/s40534-013-0020-0 陈维荣,卜庆元,刘志祥,等. 燃料电池混合动力有轨电车动力系统设计[J]. 江南娱乐网页版入口官网下载安装学报,2016,51(3): 430-436.doi:10.3969/j.issn.0258-2724.2016.03.003CHEN Weirong, PU Qingyuan, LIU Zhixiang, et al. Power system design for a fuel cell hybrid power tram[J]. Journal of Southwest Jiaotong University, 2016, 51(3): 430-436.doi:10.3969/j.issn.0258-2724.2016.03.003 陈维荣,张国瑞,孟翔,等. 燃料电池混合动力有轨电车动力性分析与设计[J]. 江南娱乐网页版入口官网下载安装学报,2017,52(1): 1-8.doi:10.3969/j.issn.0258-2724.2017.01.001CHEN Weirong, ZHANG Guorui, MENG Xiang, et al. Dynamic performance analysis and design of fuel cell hybrid locomotive[J]. Journal of Southwest Jiaotong University, 2017, 52(1): 1-8.doi:10.3969/j.issn.0258-2724.2017.01.001 陈骏亚. 有轨电车用燃料电池混合动力系统设计[D]. 成都: 江南娱乐网页版入口官网下载安装, 2016. 韩晓娟,程成,籍天明,等. 计及电池使用寿命的混合储能系统容量优化模型[J]. 中国电机工程学报,2013,33(34): 91-97.HAN Xiaojuan, CHEN cheng, JI Tianming, et al. Capacity optimal modeling of hybrid energy storage systems considering battery life[J]. Proceedings of the CSEE, 2013, 33(34): 91-97. 杨珺,张建成,桂勋. 并网风光发电中混合储能系统容量优化配置[J]. 电网技术,2013,37(5): 1209-1216.YANG Jun, ZHANG Jiancheng, GUI Xun. Capacity optimization of hybrid energy storage system in grid-connected wind and PV power generation system[J]. Power System Technology, 2013, 37(5): 1209-1216. BUERGER S, LOHMANN B, MERZ M, et al. Multi-objective optimization of hybrid electric vehicles considering fuel consumption and dynamic performance[J]. Vehicle Power & Propulsion Conference, 2011, 91(5): 1-6. ALONSA E, RUIZ J, ASTRUC D. Power management optimization of an experimental fuel cell/battery/supercapacitor hybrid system[J]. Energies, 2015, 8(7): 6302-6327.doi:10.3390/en8076302 ODEIM F, ROSE J, HEINZEL A. Power management optimization of a fuel cell/battery/super-capacitor hybrid system for transit bus applications[J]. IEEE Transactions on Vehicular Technology, 2016, 65(7): 5783-5788.doi:10.1109/TVT.2015.2456232 张抗抗,徐梁飞,华剑锋,等. 基于多目标优化的纯电动车动力系统参数匹配方法[J]. 汽车工程,2015,37(7): 757-765.doi:10.3969/j.issn.1000-680X.2015.07.004ZHANG Kangkang, XU Liangfei, HUA Jianfeng, et al. A parameter matching method for the powertrain of battery electric vehicle based on multi-objective optimization[J]. Automotive Engineering, 2015, 37(7): 757-765.doi:10.3969/j.issn.1000-680X.2015.07.004 -
