Energy Management Strategy of Hybrid Tram Based on Dynamic Degree of Hybrid
-
摘要:为了提高混合储能式有轨电车的系统效率和运行经济性，基于动态混合度和系统效率之间的关系，提出了基于动态混合度在线凸规划的混合储能式有轨电车能量管理策略. 首先基于混合储能式有轨电车各系统参数，对各部件进行建模；其次采用在线凸规划法求解，得到了系统每一时刻的最优动态混合度；最后以有轨电车的典型工况为例，在RT-LAB实时仿真平台研究动态混合度对系统效率的影响. 研究结果表明动态混合度同系统效率之间存在凸函数关系：在相同参数条件下，基于动态混合度的在线凸规划能量管理策略较传统的功率跟随式能量管理策略系统瞬时效率最高提升9.6%；当完成整条线路运行，可节省电量2 886.2 kJ，运行经济性提升3.29%.Abstract:In order to improve system efficiency and operational economy of hybrid tram, according to the relationship between dynamic degree of hybrid (DDOH) and system efficiency, a hybrid tram energy management strategy (EMS) based on DDOH online convex programming is proposed. Firstly, each component is modeled based on system parameters of the hybrid tram. Secondly, the online convex programming method is used to solve the problem, and the real-time optimal DDOH data of the system is obtained. Finally, the effect of DDOH on system efficiency is observed by RT-LAB real-time simulation platform under typical tram conditions. The results show that the relationship between DDOH and system efficiency fits a convex curve. The instantaneous efficiency is improved by 9.6% when we use DDOH online convex programming energy management strategy, compared to the situation using traditional energy-followed energy management strategy with same parameters. For a complete running circle, the power can be saved by 2 886.2 kJ, and the operational economy can be improved by 3.29%.
-
Key words:
- hybrid tram/
- DDOH/
- system efficiency/
- operational economy
-
图 7不同状态参数下动态混合度和系统瞬时效率
Figure 7.DDOH and system instantaneous efficiency under different state parameters
表 1混合储能式有轨电车主要参数
Table 1.Parameters of hybrid energy storage tram
参数 取值 应用环境温度/℃ −25～42 母线电压/V 750 车辆编组 Mc-T-Mc 轴重/t 10.5 最高运行速度/（km•h−1） 70 最大坡度/‰ 5 列车长度/m 30.19 列车宽度/m 2.65 列车自重/t 51.06 列车载员/人 267 加速度/（m•s−2） 1.2 续驶里程/km 30
下载:
导出CSV
表 2锂电池仿真参数
Table 2.Lithium-ion battery simulation parameters
参数 取值 额定电压/V 3.7 额定容量/（A•h） 10 串联数目/个 135 并联数目/个 15 初始SOC 0.85 下载:
导出CSV
表 3超级电容仿真参数
Table 3.Supercapacitor simulation parameters
参数 取值 额定电压/V 2.7 额定电容量/F 7 500 串联数目/个 222 并联数目/个 15 初始SOC 0.85 下载:
导出CSV
-
陈维荣,钱清泉,李奇. 燃料电池混合动力列车的研究现状与发展趋势[J]. 江南娱乐网页版入口官网下载安装学报,2009,44(1): 1-6.doi:10.3969/j.issn.0258-2724.2009.01.001CHEN Weirong, QIAN Qingquan, LI Qi. Investigation status and development trend of hybrid power train based on fuel cell[J]. Journal of Southwest Jiaotong University, 2009, 44(1): 1-6.doi:10.3969/j.issn.0258-2724.2009.01.001 薛美根,杨立峰,程杰. 现代有轨电车主要特征与国内外发展研究[J]. 城市交通,2008,6(6): 88-91.doi:10.3969/j.issn.1672-5328.2008.06.016XUE Meigen, YANG Lifeng, CHENG Jie. Modern trams:characteristics & development both at home and abroad[J]. Urban Transport of China, 2008, 6(6): 88-91.doi:10.3969/j.issn.1672-5328.2008.06.016 何治新. 现代有轨电车牵引供电方式选择[J]. 城市轨道交通研究,2013,16(7): 105-108.doi:10.3969/j.issn.1007-869X.2013.07.028HE Zhixin. Selection of modern tram traction power supply system[J]. Urban Mass Transit, 2013, 16(7): 105-108.doi:10.3969/j.issn.1007-869X.2013.07.028 PÉREZ V I H, GAZTAÑAGA H, MILO A, et al. Optimal energy management of a hybrid electric bus with a battery-supercapacitor storage system using genetic algorithm[C/OL]//2015 International Conference on Electrical Systems for Aircraft, Railway, Ship Propulsion and Road Vehicles (ESARS). (2015-03-05)[2018-10-12].https://ieeexplore.ieee.org/document/7101452/figures#figures. TORREGLOSA J P, GARCIA P, FERNÁNDEZ L M, et al. Predictive control for the energy management of a fuel-cell-battery-supercapacitor tramway[J]. IEEE Transactions on Industrial Informatics, 2014, 10(1): 276-285. 柯西. 南京首列有轨电车投入运营[J]. 现代城市轨道交通,2014(5): 96. 朱一迪. 首列超级电容储能式100%低地板有轨电车广州开通试乘[J]. 机车电传动,2015(1): 94. 朱一迪. 世界首列商用型燃料电池/超级电容混合动力有轨电车下线[J]. 机车电传动,2016(3): 105. HERRERA V, MILO A, GAZTAÑAGA H, et al. Adaptive energy management strategy and optimal sizing applied on a battery-supercapacitor based tramway[J]. Applied Energy, 2016, 169: 831-845.doi:10.1016/j.apenergy.2016.02.079 TALLA J, STREIT L, PEROUTKA Z, et al. Position-based t-s fuzzy power management for tram with energy storage system[J]. IEEE Transactions on Industrial Electronics, 2015, 62(5): 3061-3071.doi:10.1109/TIE.2015.2396871 杨继斌,张继业,宋鹏云,等. 混合动力列车电源系统控制策略[J]. 江南娱乐网页版入口官网下载安装学报,2015,50(1): 20-26.doi:10.3969/j.issn.0258-2724.2015.01.004YANG Jibin, ZHANG Jiye, SONG Pengyun, et al. Research on the control strategy of power system for hybrid electric train[J]. Journal of Southwest Jiaotong University, 2015, 50(1): 20-26.doi:10.3969/j.issn.0258-2724.2015.01.004 林泓涛,姜久春,贾志东,等. 权重系数自适应调整的混合储能系统多目标模型预测控制[J]. 中国电机工程学报,2018,38(18): 5538-5547.LIN Hongtao, JIANG Jiuchun, JIA Zhidong, et al. Multi-objective model predictive control for hybrid energy storage system with adaptive adjustment of weight coefficients[J]. Proceedings of the CSEE, 2018, 38(18): 5538-5547. 陈维荣,卜庆元,刘志祥,等. 燃料电池混合动力有轨电车动力系统设计[J]. 江南娱乐网页版入口官网下载安装学报,2016,51(3): 430-436.doi:10.3969/j.issn.0258-2724.2016.03.003CHEN Weirong, BU Qingyuan, LIU Zhixiang, et al. Power system design for a fuel cell hybrid power tram[J]. Journal of Southwest Jiaotong University, 2016, 51(3): 430-436.doi:10.3969/j.issn.0258-2724.2016.03.003 徐梁飞,卢兰光,李建秋,等. 燃料电池混合动力系统建模及能量管理算法仿真[J]. 机械工程学报,2009,45(1): 141-147.XU Liangfei, LU Languang, LI Jianqiu, et al. Modeling and simulation of a hybrid fuel cell system and energy management strategy[J]. Chinese Journal of Mechanical Engineering, 2009, 45(1): 141-147. 马宇辉, 刘念. 用户侧微电网的能量管理方法综述[J]. 电力系统保护与控制,2017,45(23): 158-168.doi:10.7667/PSPC170782MA Yuhui, LIU Nian. Survey on energy management method of community micro-grid[J]. Power System Protection and Control, 2017, 45(23): 158-168.doi:10.7667/PSPC170782 周林,贾芳成,郭珂,等. 采用RT-LAB的光伏发电仿真系统试验分析[J]. 高电压技术,2010,36(11): 2814-2820.ZHOU Lin, JIA Fangcheng, GUO Ke, et al. Testing analysis on a kind of PV generation simulation system using RT-LAB[J]. High Voltage Engineering, 2010, 36(11): 2814-2820. 常晓飞,符文星,闫杰. 基于RT-LAB的某型导弹半实物仿真系统设计[J]. 系统仿真学报,2009,21(18): 5720-5723.CHANG Xiaofei, FU Wenxing, YAN Jie. Design of missile hardware-in-the-loop simulation system based on RT-LAB[J]. Journal of System Simulation, 2009, 21(18): 5720-5723. 张国瑞,李奇,韩莹,等. 基于运行模式和动态混合度的燃料电池混合动力有轨电车等效氢耗最小化能量管理方法研究[J]. 中国电机工程学报,2018,38(23): 6905-6914.ZHANG Guorui, LI Qi, HAN Ying, et al. Study on equivalent consumption minimization strategy based on operation mode and DDOH for fuel cell hybrid tramway[J]. Proceedings of the CSEE, 2018, 38(23): 6905-6914. 朱谷雨,王致杰,邹毅军,等. 永磁直驱风机的小步长硬件在环仿真研究[J]. 电力系统保护与控制,2018,46(23): 111-117.doi:10.7667/PSPC171723ZHU Guyu, WANG Zhijie, ZOU Yijun, et al. Research on HIL simulation of direct-driven permanent magnet synchronous generator[J]. Power System Protection and Control, 2018, 46(23): 111-117.doi:10.7667/PSPC171723 陈亮,黄强,贾萌萌,等. 基于柔性直流互联的交直流混合配电网建模与仿真分析[J]. 电网技术,2018,42(5): 1410-1417.CHEN Liang, HUANG Qiang, JIA Mengmeng, et al. Modeling and simulation analysis of hybrid AC/DC distribution network based on flexible DC interconnection[J]. Power System Technology, 2018, 42(5): 1410-1417. 陈维荣, 胡斌彬, 李奇, 等. 基于改进动态规划算法的燃料电池混合动力有轨电车能量管理方法研究[J/OL]. 江南娱乐网页版入口官网下载安装学报, 网络首发: 1-8[2019-10-18].http://kns.cnki.net/kcms/detail/51.1277.U.20181015.1520.002.html.CHEN Weirong, HU Binbin, LI Qi, et al. Fuel cell hybrid tram power management method based on improved dynamic programming algorithm[J/OL]. Journal of Southwest Jiaotong University, Network First: 1-8[2019-10-18].http://kns.cnki.net/kcms/detail/ 51.1277.U.20181015.1520.002.html. 邓涛,韩海硕,罗俊林. 基于动态规划算法的混合动力汽车改进型ECMS能量管理控制研究[J]. 中国机械工程,2018,29(3): 326-332.doi:10.3969/j.issn.1004-132X.2018.03.012DENG Tao, HAN Haishuo, LUO Junlin. Improved ECMS energy management control of HEVs based on DP algorithm[J]. China Mechanical Engineering, 2018, 29(3): 326-332.doi:10.3969/j.issn.1004-132X.2018.03.012 王钦普,游思雄,李亮,等. 插电式混合动力汽车能量管理策略研究综述[J]. 机械工程学报,2017,53(16): 1-19.WANG Qinpu, YOU Sixiong, LI Liang, et al. Survey on energy management strategy for plug-in hybrid electric vehicles[J]. Journal of Mechanical Engineering, 2017, 53(16): 1-19. 崔纳新,步刚,吴剑,等. Plug-In并联式混合动力汽车实时优化能量管理策略[J]. 电工技术学报,2011,26(11): 155-160.CUI Naxin, BU Gang, WU Jian, et al. Real-time optimization of energy management strategy for Plug-In parallel hybrid electric vehicles[J]. Transactions of China Electrotechnical Society, 2011, 26(11): 155-160. ZHENG Chunhua, LI Weimin, LIANG Quan, et al. An energy management strategy of hybrid energy storage systems for electric vehicle applications[J]. IEEE Transactions on Sustainable Energy, 2018, 9(4): 1880-1888.doi:10.1109/TSTE.2018.2818259 杨继斌,宋鹏云,张继业,等. 混合动力现代有轨电车仿真系统研究[J]. 机械工程学报,2017,53(18): 161-168.YANG Jibin, SONG Pengyun, ZHANG Jiye, et al. Research on simulation system of hybrid modern tramway[J]. Journal of Mechanical Engineering, 2017, 53(18): 161-168. -
