Review on BIM Technology Used in Urban Rail Transit Projects
-
摘要:城市轨道交通工程是一项多专业、多角色在多约束、长周期、大投入下的复杂系统工程，采用BIM （building information modeling）技术是实现其高效率、规范化、低成本、全面协同的关键. 详细分析城市轨道交通工程建造的复杂性，总结当前城市轨道交通领域BIM技术的研究和应用现状，包括4种主要应用模式：面向建造、面向协同设计和分析、基于商业软件平台、基于开放式平台的BIM工程. 在分析当前研究及应用不足的基础上，归纳城市轨道交通工程中BIM技术面临的三大问题挑战：全生命周期大量模型共享的统一性问题；基于BIM的多专业、多CAD/CAE软件协同问题；全生命周期海量信息数字化、高效率、低成本管理与应用问题. 为弥补现有不足、解决城市轨道交通工程中BIM技术所面临的问题，提出城市轨道交通工程BIM技术发展的主要趋势：面向全生命周期一体化协同管理及平台、基于BIM的多专业正向协同三维设计、面向智能建造和运维的BIM规范性设计、基于IFC （industry foundation class）的BIM表达与共享、BIM技术与信息化的深度融合.Abstract:Urban rail transit project is a huge complicated system engineering with the properties of multi-major, multi-role, multi-constraint, long period, and large investment. Building information modeling (BIM) is a very effective technology to achieve high efficiency, standardization, low cost, and comprehensive collaboration in urban rail transit. Firstly the complexity of urban rail transit construction is analyzed in detail. Then this work summarizes the state-of-the-art BIM technology and its applications. The four kinds of BIM application modes are presented, i.e., construction-oriented, collaborative design and analysis-oriented, commercial software platform-based, and open platform-based BIM engineering. After analyzing the research and application insufficiency, the three major challenges of BIM technology application in urban rail transit are proposed: the integration of large-scale model sharing throughout the life cycle, the BIM-based multi-major, multi-CAD/CAE software collaboration, the high-efficient, low-cost management and usage of massive engineering information throughout the life cycle. Finally, to solve the existing shortcomings, the major trends of BIM technology development in urban rail transit engineering are suggested as the following five aspects: the full life-cycle integrated collaborative management and the related platform, BIM-based multi-major forward collaborative design, specification design of BIM for intelligent construction and operation, IFC (industry foundation class)-based BIM expression and sharing, deep integration of BIM technology and informatization.
-
图 3面向协同设计与分析的BIM工程
Figure 3.Collaborative design and analysis-oriented BIM engineering
图 4基于商业平台的BIM工程
BOQ—bill of quotation VPM—virtual product management KKS—设备功能位置
Figure 4.BIM engineering based on commercial platform
表 1广东省BIM建模与交付标准（部分）
Table 1.BIM modeling and delivering standard for Guangdong province （part）
模型名称 对象 工程/子
系统建模构
件/设备几何信息 非几何信息（模型内置信息） 建筑 车站 主体建筑 门窗 尺寸、空间
定位材料、型号 墙 尺寸、空间
定位材料、规格 楼梯 尺寸、空间
定位材料、规格
下载:
导出CSV
表 2广州地铁BIM建模标准（部分）
Table 2.BIM modeling standard of Guangzhou Metro (part)
模型
名称设施设备类型 几何信息 非几何信息 要素 信息内容 LOD100 LOD200 LOD300 信息内容 LOD100 LOD200 LOD300 车站
建筑墙 普通墙 宽度、高度 y y y 材料、填充图案、颜色、热膨胀系数 y y y 防火墙 宽度、高度 y y 材料、填充图案、颜色、热膨胀系数 y y 混凝土墙 宽度、高度 y y 材料、填充图案、颜色、热膨胀系数 y 其他 注：表中“y”表示模型精度等级包含该信息内容. 下载:
导出CSV
-
EASTMAN C M, EASTMAN C, TEICHOLZ P, et al. BIM handbook: a guide to building information modeling for owners, managers, designers, engineers and contractors[M]. 3rd edition. Hoboken: John Wiley & Sons, 2018. 清华大学BIM课题组. 中国建筑信息模型标准框架研究[M]. 北京: 中国建筑工业出版社, 2011. 尹亚辉. BIM技术在项目全生命周期的应用研究[D]. 北京: 北京建筑大学, 2015. CEROVSEK T. A review and outlook for a ‘Building Information Model’ (BIM):a multi-standpoint framework for technological development[J]. Advanced Engineering Informatics, 2011, 25(2): 224-244.doi:10.1016/j.aei.2010.06.003 纪博雅,戚振强. 国内BIM技术研究现状[J]. 科技管理研究,2015,35(6): 184-190.doi:10.3969/j.issn.1000-7695.2015.06.035JI Boya, QI Zhenqiang. BIM technology research status in China[J]. Science and Technology Management Research, 2015, 35(6): 184-190.doi:10.3969/j.issn.1000-7695.2015.06.035 张建平,王洪钧. 建筑施工4D++模型与4D项目管理系统的研究[J]. 土木工程学报,2003,36(3): 70-78.doi:10.3321/j.issn:1000-131X.2003.03.014ZHANG Jianping, WANG Hongjun. A 4D++ site model and 4D management system for construction projects[J]. China Civil Engineering Journal, 2003, 36(3): 70-78.doi:10.3321/j.issn:1000-131X.2003.03.014 LI Y F, WANG H C, ZHAO X F, et al. Research on BIM technology application in the construction of a subway station[J]. Applied Mechanics and Materials, 2013, 405/406/407/408: 3396-3400.doi:10.4028/www.scientific.net/AMM.405-408.3396 杨永平,边颜东,周晓勤,等. 我国城市轨道交通存在的主要问题及发展对策[J]. 城市轨道交通研究,2013,16(10): 1-6.YANG Yongping, BIAN Yandong, ZHOU Xiaoqin, et al. Problems and development strategy of urban railtransit in China[J]. Urban Mass Transit, 2013, 16(10): 1-6. 郭杰. 城市轨道交通工程接口管理研究[D]. 北京: 中国铁道科学研究院, 2011. 张金伟,刘志广,路清泉,等. 城市轨道交通工程BIM技术应用推广实施方法研究[J]. 现代隧道技术,2019,56(3): 45-52,71.ZHANG Jinwei, LIU Zhiguang, LU Qingquan, et al. On application and promotion of BIM technique in urban rail transit engineering[J]. Modern Tunnelling Technology, 2019, 56(3): 45-52,71. LI R J, SHAN R L, LIAO Q L, et al. New developments and applications in rail transit construction technology[J]. Applied Mechanics and Materials, 2014, 580/581/582/583: 1065-1071.doi:10.4028/www.scientific.net/AMM.580-583.1065 LAAKSO M, KIVINIEMI A. The IFC standard − a review of history,development,and standardization[J]. Journal of Information Technology in Construction, 2012, 17(9): 134-161. 中国建筑科学研究院, 中国标准化研究院, 清华大学, 等. 工业基础类平台规范: GB/T 25507—2010[S]. 北京: 中国标准出版社, 2010. ZHANG L, el-GOHARY N M. Automated IFC-based building information modelling and extraction for supporting value analysis of buildings[J]. International Journal of Construction Management, 2020, 20(4): 269-288.doi:10.1080/15623599.2018.1484850 林佳瑞,张建平. 基于IFC的绿色性能分析数据转换与共享[J]. 清华大学学报(自然科学版),2016,56(9): 997-1002.LIN Jiarui, ZHANG Jianping. Data conversion and sharing for building performance analyses based on IFC[J]. Journal of Tsinghua University (Science and Technology), 2016, 56(9): 997-1002. 李浩,赵国堂,范丁元,等. 面向GIS应用的铁路工程三维信息模型数据交换方法[J]. 江南娱乐网页版入口官网下载安装学报,2018,53(1): 197-205.doi:10.3969/j.issn.0258-2724.2018.01.024LI Hao, ZHAO Guotang, FAN Dingyuan, et al. Data exchange method of railway engineering information model for GIS applications[J]. Journal of Southwest Jiaotong University, 2018, 53(1): 197-205.doi:10.3969/j.issn.0258-2724.2018.01.024 赵铁柱. 城市轨道交通站台门参数化三维建模软件开发与应用[J]. 城市轨道交通研究,2017,20(5): 147-152.ZHAO Tiezhu. Development and application of 3D parametric modeling software for urban rail transit platform screen door system[J]. Urban Mass Transit, 2017, 20(5): 147-152. 邓雪原. CAD、BIM与协同研究[J]. 土木建筑工程信息技术,2013,5(5): 20-25.DENG Xueyuan. The study of CAD, BIM and collaboration[J]. Journal of Information Technology in Civil Engineering and Architecture, 2013, 5(5): 20-25. 韩亮亮. 基于3D EXPERIENCE平台的铁路设备BIM模型轻量化技术研究[J]. 科技创新与应用,2020(5): 19-22.HAN Liangliang. Research on lightweight technology of railway equipment BIM model based on 3D EXPERIENCE platform[J]. Technology Innovation and Application, 2020(5): 19-22. 吕婧,金浩然,谭军,等. glTF在BIM模型轻量化中的应用[J]. 科技创新与应用,2020(6): 174-176. 王巧雯,张加万,牛志斌. 基于建筑信息模型的建筑多专业协同设计流程分析[J]. 同济大学学报(自然科学版),2018,46(8): 1155-1160.WANG Qiaowen, ZHANG Jiawan, NIU Zhibin. Architecture multi-disciplinary collaborative design process based on building information model[J]. Journal of Tongji University (Natural Science), 2018, 46(8): 1155-1160. 史海欧,袁泉,张耘琳,等. 基于BIM交互与数据驱动的多专业正向协同设计技术[J]. 江南娱乐网页版入口官网下载安装学报,2021,56(1): 176-181.SHI Haiou, YUAN Quan, ZHANG Yunlin, et al. Multi-discipline forward collaborative design technology based on BIM interaction and data-driven[J]. Journal of Southwest Jiaotong University, 2021, 56(1): 176-181. 高云. 高层建筑火灾烟雾颗粒物扩散路径监测方法研究[J]. 环境科学与管理,2020,45(1): 131-135.doi:10.3969/j.issn.1673-1212.2020.01.026GAO Yun. Research on monitoring method of smoke particles diffusion path in high-rise building fire[J]. Environmental Science and Management, 2020, 45(1): 131-135.doi:10.3969/j.issn.1673-1212.2020.01.026 EL-DIRABY T, KRIJNEN T, PAPAGELIS M. BIM-based collaborative design and socio-technical analytics of green buildings[J]. Automation in Construction, 2017, 82: 59-74.doi:10.1016/j.autcon.2017.06.004 王勇,李久林,张建平. 建筑协同设计中的BIM模型管理机制探索[J]. 土木建筑工程信息技术,2014,6(6): 64-69.doi:10.3969/j.issn.1674-7461.2014.06.012WANG Yong, LI Jiulin, ZHANG Jianping. Exploration of BIM management mechanism in collaborative design[J]. Journal of Information Technology in Civil Engineering and Architecture, 2014, 6(6): 64-69.doi:10.3969/j.issn.1674-7461.2014.06.012 YANG T, LU Y Q, QIN H Y. Catia-based BIM technology in highway tunnel design[J]. Stavební Obzor:Civil Engineering Journal, 2019, 28(3): 469-482. 陈宇,庞艳婷,朱嘉. ENOVIAVPM系统平台在城市轨道车辆协同设计中的应用[J]. 电子技术与软件工程,2016(21): 75. YANG H X. Integration model of construction management of BIM construction project based on IFC[J]. Journal of Computational and Theoretical Nanoscience, 2016, 13(12): 9368-9372.doi:10.1166/jctn.2016.5849 HU Z Z, ZHANG J P. BIM- and 4D-based integrated solution of analysis and management for conflicts and structural safety problems during construction:2. development and site trials[J]. Automation in Construction, 2011, 20(2): 167-180.doi:10.1016/j.autcon.2010.09.014 LI X, XU J, ZHANG Q. Research on construction schedule management based on BIM technology[J]. Procedia Engineering, 2017, 174: 657-667.doi:10.1016/j.proeng.2017.01.214 张飞涟,郭三伟,杨中杰. 基于BIM的建造工程项目全寿命期集成管理研究[J]. 铁道科学与工程学报,2015,12(3): 702-708.doi:10.3969/j.issn.1672-7029.2015.03.038ZHANG Feilian, GUO Sanwei, YANG Zhongjie. Research on the life cycle integrated management of construction projects based on BIM[J]. Journal of Railway Science and Engineering, 2015, 12(3): 702-708.doi:10.3969/j.issn.1672-7029.2015.03.038 广州地铁集团有限公司. 城市轨道交通建筑信息模型（BIM）建模与交付标准: DBJ/T 15-160—2019[S]. 广州: 广东省住房和城乡建造厅, 2019. 广州地铁设计研究院有限公司. 城市轨道交通BIM模型交付标准: Q/GZDTSJY-QEOB-045—2015[S]. 广州: 广州地铁设计研究院有限公司, 2015. PAZLAR T, TURK Ž. Interoperability in practice:geometric data exchance using the IFC standard[J]. Journal of Information Technology in Construction, 2008, 13: 362-380. WON J, LEE G, CHO C. No-schema algorithm for extracting a partial model from an IFC instance model[J]. Journal of Computing in Civil Engineering, 2013, 27(6): 585-592.doi:10.1061/(ASCE)CP.1943-5487.0000320 BIRGING E. Integration of BIM in the construction phase a study of a Swedish construction project based on interviews[D]. Göteborg: Chalmers University of Technology, 2014. 杨新,焦柯,鲁恒,等. 基于BIM的建筑正向协同设计平台模式研究[J]. 土木建筑工程信息技术,2019,11(4): 28-32.YANG Xin, JIAO Ke, LU Heng, et al. Research on forward collaborative design platform of buildings based on BIM[J]. Journal of Information Technology in Civil Engineering and Architecture, 2019, 11(4): 28-32. 张洋. 基于BIM的建筑工程信息集成与管理研究[D]. 北京: 清华大学, 2009. SUN C L, LIU C, SHI D. Construction and application of integration under IFC standard based on BIM database[J]. Advanced Materials Research, 2014(5): 1894-1897. 施平望,林良帆,邓雪原. 基于IFC标准的建筑构件表达与管理方法研究[J]. 图学学报,2016,37(2): 249-256.SHI Pingwang, LIN Liangfan, DENG Xueyuan. Research on representation and management of IFC-based building components[J]. Journal of Graphics, 2016, 37(2): 249-256. 何志红,孙会龙,刘贞,等. 基于BIM + VR技术的装配式建筑远程协同平台设计[J]. 重庆理工大学学报(自然科学),2019,33(10): 96-102.HE Zhihong, SUN Huilong, LIU Zhen, et al. Design of remote collaborative platform for prefabricated construction based on BIM + VR technology[J]. Journal of Chongqing University of Technology (Natural Science), 2019, 33(10): 96-102. 卫星, 邹建豪, 肖林, 等. 基于BIM的钢桁梁桥裂纹病害信息数字化管理[J/OL]. 江南娱乐网页版入口官网下载安装学报, 2019: 1-9. (2019-10-13)[2020-01-13].http://kns.cnki.net/kcms/detail/51.1277.U.20191023.1121.013.html.WEI Xing, ZOU Jianhao, XIAO Lin, et al. Digital management of crack disease information in steel struss bridges based on BIM[J/OL]. Journal of Southwest Jiaotong University, 2019: 1-9. (2019-10-13)[2020-01-13].http://kns.cnki.net/kcms/detail/51.1277.U.20191023.1121.013.html. -
